Apply for:
1) Plastic film, composite film, aluminum foil, aluminized film, etc.;
2) Plastic sheets, plates, rubber, ceramics, etc.;
3) Packaging containers, such as bottles, bags, bowls, etc.;
4) Expand applications, such as solar backplanes, liquid crystal display films, medical patches, etc.
Used in quality inspection, drug inspection, scientific research, packaging, film, food, pharmaceutical, daily chemical, electronics and other industries.
Specification
Items | Technical Parameters |
Standards | ASTM D3985, ASTM F2622, ASTM F1927, ASTM F1037, ISO 15105-2, JIS K-7126-B, DIN 53380-3 |
Temperature precision | ±0.1℃ |
Temperature | 15～45℃ |
Accuracy | 0.001 cm3/（m2·24h） |
Range | 0.02～1000 cm3/（m2·24h） |
Sample dimension | Φ100 mm |
Sample thickness | ≤3mm |
Test area | 50.24 cm2 |
Carrier gas pressure | ≥0.1MPa |
Carrier gas flow | 5~100 mL/min |
Carrier gas | 99.999% nitrogen (provided by the user) |
Number of samples | 1 pc |
Pneumatic pressure | ≥0.3MPa |
Power | 450W |
Power supply | AC 220V，50Hz |
Features
Advanced technology
◆ Temperature control: Adopting the international advanced electromagnetic program stepping temperature control technology, automatic heating and cooling; high measurement accuracy, accurate to 0.1 ℃.
◆ Support electronic signature function, online report submission and review.
Accurate and reliable data
◆ Our company has approved and issued by the "General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China". Gas Permeability Tester "National Standard Material Classification Certificate" and "National Standard Material" Manufacturing Measuring Instruments License (GBW(E)130541/ Use national standard materials to calibrate and verify the instrument to ensure the accuracy, versatility and authority of the test data.
High test efficiency
◆ The measurement accuracy is up to 0.001 cm3/(m2·24h), and it can measure high-barrier materials such as aluminum foil.
Authority management and data tracking
◆ The software is designed according to the requirements of the computerized system in the new GMP appendix.
◆ The user name and password are required to log in to the workstation to ensure that the account and experimental data are safe and effective.
◆ Users are divided into system administrator, instrument administrator, auditor and operator.
◆ The system administrator can adjust the permissions of various levels; Such as adding and reducing system control items at a certain level.
◆ It has audit tracking function (test tracking and log tracking), and each data change is recorded; Ensure the safety and integrity of test data.
Easy to operate
◆ Professional software with simple interface, easy to use and flexibly to set test process.
◆ Fully automatic operation, judge and stop automatically.
◆ Five sets of curves of temperature, upper cavity pressure, lower cavity pressure, pressure difference change, and penetration are displayed in real time. The curves with conceal function, support query function for background data.
◆ The OTR is equipped with a color touch screen, no external computer is needed.
◆ Pneumatic clamps are used for sample placement, which is quick and convenient to operate.
◆ Professional test report, automatically generate and can be exported in PDF format.
Stable, reliable and easy to maintain
◆ Imported oxygen sensor with high accuracy and good stability.
◆ The sensor has an over-range automatic protection function to avoid damage to important sensors when the instrument fails
◆ Functional modular design, easy to maintain.
