Standards
GB/T 15171-1994, ASTM D3078-2002（2013）
Features
◆ Compressed air，pneumatic drive.
◆ Wholly automatic, auto vacuum and keep for set time, auto stop and return.
◆ Can manually pause and stop.
◆ LCD display test data and working status.
Specifications
Item | Technical Parameters |
Vacuum degree | 0~-95Kpa |
Vacuum precision | ±1%(indication error) |
Vacuum keeping time | 0.1s~60min |
Compressed air pressure | 0.4~0.6 Mpa(4~6 kgf/cm2) |
Compressed air consumption | 20 L/min |
Vacuum chamber size | Φ270mm × 270mm |
Instrument size | Instrument size:580mm × 345mm × 440mm Vacuum tank:Ø300 × 300mm（samll） Ø450 × 350mm(medium) |
Net weight | 12 kg |
Working temperature | 10~40℃ |
Vacuum degree | 0~ -95kPa |
Power supply | AC 220V 50Hz |
Configuration List
Spare parts | |||
NO. | Name | Remark | Quantity |
1 | Leakage tester | GB-M2 | 1 set |
2 | Power cable | / | 1 PC |
3 | Air pipe | / | 1 M |
4 | Vacuum tank+lid | / | 1PC |
Note: GBPI is always committed to product innovation and improved performance, so accordingly product technical specifications are subject to change without notice. GBPI reserves the right to amend and the final power of interpretation.
