Application
Used to detect the gloss of plastic film, paper, ink, adhesive, etc. Multi-point measurement and data processing can be performed on the sample, and parameters such as average value, standard deviation and coefficient of variation can be printed directly. The machine has high precision and good stability, and can measure the glossiness of flat products such as paint, paper, plastic, ceramic, stone and metal.
Specifications
Item | Specification |
Test range | 0-199.9 Gloss units |
Precision | ±1.0 Gloss units |
Stability | Not more than 0.5 gloss unit / every 30 minutes |
Repeatability | Not more than 0.5 gloss unit |
Measuring probe size | 180mm×100mm×50mm |
Power | 25w/ 220vAC，50HZ |
Standards
Angle | International Standard | Chines Standard | Application |
20 | ISO-2813 ISO8254 | GB9754 GB8807 | Coating Plastic |
20 | TAPPI-T653 ASTM-D1834 | GB8941.1 | Paper |
45 | ISO-2767 | GB8941.2 | Metal compound paper |
45 | ASTM-C346 ASTM-D2457 | GB8807 | Ceramics、Plastic |
45 | JIS-E8741 | Coating | |
60 | ISO-2813 ASTM-D2457 | GB9754 GB9966 GB8807 | Coating Stone Plastic |
75 | TAPPI-T480 | GB9841.3 | Paper |
85 | ISO-2813 | GB9754 | Coating |
Feature
◆ Full-function intelligent design, light touch key operation.
◆ Automatic measurement and manual measurement function.
◆ For single point or no more than 10 points measurement, calculate the average value, root mean square, coefficient of variation and print out the result.
